One-part,gray,moisture RTV,fast cure,UL.
Properties
These values are not intended for use in preparing specifications.
Typical Properties
-
Adhesion toAluminum, Ceramic, FR4, Metal, Plastic
-
ColorGray
-
Cure CharacteristicsRoom Temperature Fast Tack-Free < 10 min
-
Cure TypeAlkoxy Cure, Methoxy Cure
-
Dielectric Constant at 100 Hz2.22
-
Dielectric Constant at 100 kHz2.38
-
Dielectric Strength500 volts per mil v/mil
-
Dissipation Factor at 100 Hz0.003
-
Dissipation Factor at 100 kHz< 0.0002
-
Durometer - Shore 0083 Shore 00
-
Durometer - Shore A35 Shore A
-
Elongation185 %
-
HydrophobicYes
-
Linear CTE250 um/m/Deg C
-
Low OdorYes
-
Non-SlumpYes
-
NonflowableYes
-
Number of PartsOne
-
PolyestersYes
-
Primerless AdhesionPrimerless
-
Resistance TypeOxidation Resistance, Ozone Resistance, Thermal Resistance, UV Resistance, Water Resistance
-
Room Temperature Cure - Hours24 Hours
-
Shear200 psi
-
Shelf Life360 Days
-
SolventlessYes
-
Special CharacteristicsOne Part, UL Recognized
-
Specific Gravity @ 25°C1.35
-
Tack-Free Time-50% RH5 Minutes
-
Temperature Range-45 to 200 °C
-
Temperature StableHigh, Low
-
Tensile Strength (SI)0.9 MPa
-
ThermosettingYes
-
ThixotropicYes
-
Volume Resistivity2.4e+015 Ω・cm
-
Water ResistantYes
